HPI RACING 1:10 EP Touring Car ATC 2.4 4WD Brushless RTR

Highlights & Details: +60km/h � 4WD Water-resistant brushless speed controller 3421KV brushless motor Pre-printed race body !!!! INCLUDING A DRIFT WHEEL SET - FO FREE !!!! Features: Ready assembled Water-resistant 50A brushless speed controller 2.4 GHz radio system "CR2S" 4 kg steering servo 4WD Complete ball bearing Aluminum adjustable oil shocks 2 gear differentials 3421KV brushless motor Aluminum chassis stiffener Steel shafts - front/rear Full adjustable chassis Aluminum motor mount Aluminum drive shaft Pre-printed body Steel transmission (spur gear and pinion gear) Technical specifications: Measure: ( L/W/H) 450x190x140 mm Weight: 1425g Radstand 260 mm Chassis clearance: 20 mm Front track 170 mm / Rear track 170 mm Tires: ? � 65 mm / Width 27mm front/rear Chassis: ATC Viskosity Shock Oil: 300CPS f/r Shock Size: front 62mm / rear 62mm Internal transmission: 13T / 38T Motor transmission: Spur gear 64T / Pinion gear 29T (Module 0.6) Technical specification speed controller Thrust: Water resistant 50A controller incl. cooler 3S LiPo suitable T-plug battery connector Gold-bonded motor connector 3.5mm Easy calibration and programming Sensorless NiMH 4 - 9 cells / LiPo 2 - 3 cells Overheat protection: 95� Peak amps: 300A BEC 6V / 3A Operating voltage 4.8 � 11.1V Motor timing 18.75 deg. Motor limit @2S LiPo / 6 cells NiMH = Onroad < 8T / Offroad < 11T Motor limit @3S LiPo / 9 cells NiMH = Onroad < 11T / Offroad < 14T Programmable functions: Brake power 25% - 100% Neutral brake 0% - 40% Drive mode: forward-brake-backwards / forward-brake Start mode (Punch): Level 1-4 (soft - aggressiv) Low voltage cutt-off: off - 3.4V (default setting: 3.0V) Technichal data : Measure (L/W/H) : 48.5 x 38 x 32 mm Weight: 90g Technichal data motor Thrust: 3421 KV 27.400 RPM/min @ 7.4 Volt 4 Pole Operating voltage: 4.8 � 11.1V Motor size: 540 Motor length: 52.0 mm Motor ? : 36.0 mm Shaft length: 14.5 mm Shaft ?: 3,17 mm Technical data servo S40PH: Size: Standard (Car) Operating force: 4,0kg @ 4,8V Speed: 0,16 Sec / 60� @ 4,8V Gears: Nylon Outdrive: 25T Plug system: JR Measure: (LxWxH) 40,2 mm x 20,4 mm x 39,8 mm Voltage: 4.8V - 6.6V Weight: 43g Ball bearing Technical data radio system: 2-channel radio 3-channel mini receiver Reverse function Dual rate and trimming adjustable Battery case for 4 Mignon AA cells (not included) Scope of delivery: 1 pcs. ATC2.4 Touring Car brushless RTR ( Incl. Motor, Speed controller, Steering servo - ready assembled) � Radio system � Manual Required accessories: NiMH Racing pack or LiPo battery � Charger � 4 Mignon AA cells (radio)
